Description
Scope of Delivery:
- 1x BENNING current clamp multimeter 10 mA - 600 A AC/DC
- Supplied with case, batteries (6 x 1.5 V Micro) and test leads, for spare batteries see art. no. 4000 901 810
Product Description:
with logging function and Bluetooth® interface 4-digit illuminated LCD display (9,999 dots) with bar graph - extended current measuring range via optional flexible AC current clamp transformer BENNING CFlex 1, (optional accessory - not included in the scope of delivery) AC current range 300.0 A/ 3000 A - data logger function LOG (9,999 measured values, sampling rate: 1 s - 10 min.) - memory function MEM (1,000 measured values, automatic memory function A-SAVE) - interface: Bluetooth® Low Energy 4.0 - Free IOS and Android APP for online transmission and download of the data logger/memory - Power analysis in single-phase, three-phase and DC networks - Inrush current measurement (INRUSH) of motors and lighting systems - Low-pass filter (high-frequency suppression HFR) for measurements on motor drives - THD measurement (total harmonic distortion) of harmonics - Integrated voltage sensor signals phase voltages and cable breaks in lines (optical) without contact - Automatic measuring range and function selection - Automatic switch-off (APO after 15 min., can be deactivated), battery undervoltage display - Measured value memory (HOLD), MAX, MIN, average value memory (MAX/ MIN/ AVG), peak value memory (PEAK-HOLD) - Measuring category CAT IV 600 V, CAT III 1000 V Measuring ranges: Direct current (10 mA - 600 A/ measuring ranges 99.99 A/ 599.9 A), alternating current (10 mA - 600 A/ measuring ranges 99.99 A/ 599.9 A), voltage (10 mV - 1000 V), resistance (0.1 Ω - 100 kΩ), frequency 0.01 Hz - 10 kHz, capacitance 1 nF - 4 mF, active power measurement 1 W - 600 kW, power factor cos phi 0.01 - 1.00, inrush current measurement (INRUSH), THD measurement, rotary field direction display, continuity test (30 Ω - 100 Ω), diode test (1.8 V)
Technical Data:
- Width: 103mm
- Length: 243mm
- Pliers opening: 33mm
- height: 55mm
- subject to test: yes
- Measuring method: TRUE RMS
- Brand: BENNING
- Measurement category: CAT IV 600 V
- Measuring range: 10 mA - 600 A AC/DC Note on the disposal of batteries and rechargeable batteries As we sell batteries and rechargeable batteries or devices containing batteries and rechargeable batteries, we are obliged under the Battery Act (BattG) to draw your attention to the following: The symbol of the crossed-out dustbin on batteries or accumulators means that they must not be disposed of with household waste after use. If batteries or accumulators contain mercury, cadmium or lead, you will find the respective chemical symbol (Hg, Cd or Pb) below the symbol of the crossed-out dustbin. Every user of batteries or accumulators is legally obliged to return old batteries and accumulators. You can do this free of charge at a retail outlet or other collection point in your area. You can obtain the addresses of suitable collection centres in your area from your city or local authority. For batteries that contain more than 0.0005 per cent mercury by mass, more than 0.002 per cent cadmium by mass or more than 0.004 per cent lead by mass, the chemical designations of the pollutant used can be found under the waste bin symbol. The chemical designations have the following meaning: Pb: Battery contains lead Cd: Battery contains cadmium Hg: Battery contains mercuryFor commercial use, please observe the building regulations!
For commercial use, please observe the building regulations!
